Ortofon VERTO - MC transformer (dual mono step-up transformer)

Article number: 11007674
RRP: 1,010.00 2 849.00

You save: 16 %

VAT included Plus shipping costs  (from 0.00 )
3% discount: 823.53 For payment by cash in advance (bank transfer) or pickup on the spot
Sold out
Storage alert

Highlights

    dual mono step-up transformer
    internal jumpers for gain and impedance
    gold plated RCA connectors with Teflon insulation
    minimal internal wirering, high quality PCB
    excellent shielded due to Mu-Metal can and metal cabinet
    transformers made for Ortofon by Lundahl transformers
    device works without power supply, therefore no interference from the mains
    beautiful design and excellent worksmanship
    small size for installation near record player
    we are specialized dealer for Ortofon hifi products - your authorized reseller in Leipzig, Germany


Article Description

The Ortofon Verto reserved for the discerning audiophiles and music lovers. The Verto combines the fine components along with world-class engineering, for unparalleled sound reproduction.

Starting with high quality Lundahl™ transformers, surrounded by a specialized mu-metal shielding, listeners can be assured that every detail in a complex array of notes is reproduced with utter purity, with freedom from internal and external sources of interference. These two items combined make the Verto transformer one of the quietest, most revealing transformers.

Featuring dual mono design, the Verto provides discrete circuitry for each channel, resulting in the elimination of crosstalk and possible distortions. This results in cleaner, clearer reproduction with substantially increased stereo imaging. Regardless of the composition being played, the Verto’s expansive stereo separation provides lifelike realism, and accurate tonal balance devoid of coloration.

To further minimize signal degradation and maximize signal flow, the Verto has been engineered using high quality industrial grade PCB. Additionally, gold plated RCA jacks with Teflon insulation provide optimal conductivity for use with high quality interconnects. Internally, the unit is assembled with an absolute bare minimum of internal wiring, preserving absolute signal integrity.

Verto maintains compatibility with most Moving Coil cartridges, with internal jumpers offering two gain/impedance options. This affords audiophiles with broad flexibility while still maintaining a clean aesthetic.



Technical Data

Ortofon - Verto
Konfiguration / Configuration 1
Empfohlener Abschlusswiderstand des Tonabnehmers / Recommended cartridge impedance: 5-50 Ohm
Frequenzgang / Frequency response: 10 - 100.000Hz ± 1dB
Verstärkungsfaktor / Gain: 24dB @ 1kHz
Ausgangsspannung / Output Voltage: 3,17mV @ 0,2mV / 1kHz
Ausgang / Recommended load: 47kOhm / 200pF
Konfiguration / Configuration 2
Empfohlener Abschlusswiderstand des Tonabnehmers / Recommended cartridge impedance: <10 Ohm
Frequenzgang / Frequency response: 10 - 80.000Hz ± 1dB
Verstärkungsfaktor / Gain: 30dB @ 1kHz
Ausgangsspannung / Output Voltage: 6,32mV @ 0,2mV / 1kHz
Ausgang / Recommended load: 47kOhm / 200pF
Allgemein / General
Maße (B x H x T) / Dimensions (W x H x D): 75 mm x 125 mm x 170 mm
Gewicht Weight: 940 g mit Netzteil / with power supply


Lieferumfang

  • 1 x Ortofon - Verto - MC transformer in silver/black
  • 1 x instructions
