AVM
AVM EVOLUTION CS5.2 - all-in-one device (streaming / CD receiver / 2 x 330 Watt / silver)
Article number: 11007546
5,490.00 €
3% discount: 5,325.30 €
For payment by cash in advance (bank transfer) or pickup on the spot
Sold out
Highlights
 |
4 line inputs, 1 phono input (MM & MC) | |
|
1 Pre Out, 1 Line Out | |
|
3 digital inputs (SPDIF, opt., synchronous USB- input) | |
|
2 digital outputs (S/PDIF, optical) | |
|
pure CD drive with Slot-in, spring mounted | |
|
supported media server: UPnP 1.1, UPnP-AV and DLNA-compatible server, Microsoft Windows Media Connect Server (WMDRM 10), DLNA-compatible servers: NAS | |
|
web radio: vTuner Internet Radio Service, Auto network config., Internet Radio Station database (automatic updates) | |
|
digital signal processing with 192 kHz / 24 Bit (Upsampling of all incoming digital signals into this format) | |
|
streaming formats: MP3 , WMA, AAC, OGG Vorbis, FLAC (192/32 via LAN), WAV (192/32 via LAN), AIFF (192/32 via LAN), ALAC (96/24 via LAN) | |
|
WLAN & LAN | |
|
FM-RDS-Tuner | |
|
highly efficient power amps with 330 W/ch | |
|
pure Class-A headphone output with 3,5mm plug | |
|
sleepmode: Maintains network access and enables switching the CS 5.2 on and off via the RC 9 remote control and AVM RC S App | |
|
tone control and parametric loudness with bypass-function | |
|
large blue graphic display | |
|
vast menu functions (i.e. adjustable input sensitivity, individual naming of inputs etc.) | |
|
RC S remote control app for iOS and Android | |
|
we are dealer for several more HiFi products - your authorized dealer in Leipzig |
Product description
EVOLUTION CS 5.2 - Compact Streaming CD-Receiver with 2 x 330 Watt
Our most compact music system in the EVOLUTION line is our CS 5.2. It offers the large power of more than 330 Watts per channel. The CS 5.2 offers a large variety of connectivity and control functions. Every well known format is supported when music is streamed from different sources. Furthermore the CS 5.2 offers a variety of digital inputs like synchronous USB input and SPDIF in and outputs. A NAS or externa drive are supported as well as a USB jump drive (stick). An excellent phono stage is included too as well as 3 line inputs. The firmware of the streaming client is updateable and upgradeable, making the CS 5.2 future proof. This way possible future formats may be implemented as well.
With it’s 330 Watt/ch strong amplifier, the CS 5.2 easily handles all speakers in the market. Cutting edge technologies are applied when it comes to digital signal processing with all digital signals being up sampled to 192kHz/ 24bit and a dual DAC converting to analog signal from this format. All this ensures a perfect music reproduction from every applicable source. Special focus was put on achieving the most authentic reproduction from CD. The acoustically shielded Pure CD drive is spring mounted end effectively protected from vibrations and footfall.
Like all AVM hi-fi components the CS 5.2 is carefully developed and assembled by our engineers in Malsch, Germany. Our vendors for housing and electronic parts reside all near-by. This proximity helps us to easily ensure and maintain superb quality level of the supplied parts for the AVM hi-fi components made of these.
During the manufacturing process we perform repeatedly numerous tests to insure the absolute quality of our products. When the assembling is finished and the first inspection is done all units must pass a run in test in order to prove their reliability. After that a careful final inspection follows before packing & shipping. All this ensures creating a perfect product from AVM for our customers.
The beautiful RC 9 remote control with color display is available as an option. This programmable and rechargeable remote control always comes with a charging dock.
The AVM RC S App for iOS and Android devices will turn your smartphone or tablet into an easy-to-use remote control for your AVM audio components with integrated streaming capabilities and provides a variety of intuitive features to get the most out of your network-enabled AVM HiFi device.
Discover your own personal sound experience
In our living room studio "Klangvilla" in Leipzig we feature more AVM and other hi-fi products which are at all times ready for presentation. You will have the option to be explained and demonstrated also other high-quality high-end devices by our sales manager who will be available for you. We can also recommend the appropriate wiring and other high quality Hi-Fi accessories. Simply arrange a consultation or demonstration with our sales manager for home hi-fi.
Technical Data
| AVM - EVOLUTION CS2.2 | ||||||||
| Hersteller / | Manufacturer: | AVM | ||||||
| Produktname / | Product name: | EVOLUTION CS2.2 | ||||||
| Produkttyp / | Product type: | Streaming CD-Receiver | ||||||
| Besonderheit des Geräts / | Special feature of the device: | All-In-One Gerät / all-in-one device | ||||||
| Farbe / | Colour: | silber / silver | ||||||
| Verstärker / Amplifier | ||||||||
| Empfindlichkeit Hochpegel / | Sensitivity high level: | 12,5 mV – 125 mV | ||||||
| Empfindlichkeit Phono / | Sensitivity phono: | 40 µV – 400 µV | ||||||
| Eingangsimpedanz Hochpegel / | Input impedance high level: | 6,8 kOhm | ||||||
| Eingangsimpedanz Phono / | Input impedance phono: | 47 kOhm / 100 pF | ||||||
| Störabstand Hochpegel / | SNR high level: | 96 dB(A) | ||||||
| Störabstand Phono / | SNR Phono | 83 dB(A) | ||||||
| Kanaltrennung / | Channel separation: | 55 dB | ||||||
| Frequenzgang / | Frequency response: | <5 Hz - >50 kHz | ||||||
| Klirrfaktor / | THD: | <0,1% @ 25 W/4 Ohm | ||||||
| Dämpfungsfaktor / | Damping Factor: | >200 | ||||||
| Leistung / | Output: | 4 Ohm: 2 x 330 Watt
8 Ohm: 2 x 190 Watt |
||||||
| Tuner | ||||||||
| Frequenzbereich / | Frequency range: | 87,5 - 108,0 MHz | ||||||
| Abstimmschritt / | Tuning step: | 50 kHz | ||||||
| Empfindlichkeit / | Sensitivity: | 1,5 µV / 50 µV (mono / stereo) | ||||||
| Störabstand / | SNR: | 73 / 68 dB(A) (mono / stereo) | ||||||
| CD, digital in/out | ||||||||
| Formate / | Formats: | CD-Audio, CD-R | ||||||
| Upsampling / | Upsampling: | 192 / 24 Bit | ||||||
| Frequenzgang / | Frequency response: | <5 Hz - 20 kHz | ||||||
| Deemphasis / | Deemphasis: | ja, automatisch / yes, automatically | ||||||
| Digital-Eingänge / | Digital inputs: | S/PDIF: 33–192 kHz TOSLINK: 16–24 Bit |
||||||
| USB-Eingang / | USB input: | bis/ up to 48 kHz / 16 Bit | ||||||
| Digital-Ausgänge / | Digital outputs: | S/PDIF: 44,1 kHz
TOSLINK: 16 Bit oder Eingangsformat / or input format |
||||||
| Streaming | ||||||||
| Streaming Formate / | Streaming formats: | MP3 , WMA, AAC, OGG Vorbis, FLAC (192/32 über/through LAN), WAV (192/32 über/through LAN), AIFF (192/32 über/through LAN), ALAC (96/24 über/through LAN) | ||||||
| Unterstütze Medienserver / | Supported media server: | UPnP 1.1
UPnP-AV & DLNA-kompatible/compatible Server Microsoft Windows Media Connect Server (WMDRM 10) DLNA-kompatible Server / DLNA compatible server: NAS |
||||||
| Unterstützte Streaming Services / | Supported streaming services: | TIDAL, Qobuz | ||||||
| Webradio / | Webradio: | Airable Internet Radio Service
Auto network config. Internet Radio Station database (automatic updates) |
||||||
| Digitale Signalverarbeitung / | Digital signal processing: | 192kHz / 24Bit (Upsampling aller einkommenden Signale erfolgt auf dieses Format / upsampling of all incoming signals is done in this format) | ||||||
| Netzwerkverbindung / | Network connection: | LAN & WLAN/WIFI | ||||||
| Allgemeines / General | ||||||||
| Stromverbrauch / | Power supply: | 230/50Hz oder/or 120V/60Hz | ||||||
| Leistungsaufnahme / | Power consumption: | 990 W | ||||||
| Maße (B x H x T) / | Dimensions (W x H x D): | 430 mm x 130 mm x 370 mm | ||||||
| Gewicht / | Weight: | 13 kg | ||||||
| Garantie / | Warranty: | 3 Jahre / years | ||||||
Scope of Delivery
- 1 x AVM - EVOLUTION CS2.2 - all-in-one device in silver
- 1 x power supply
- 1 x WiFi antenna
- 1 x operating instruction
